<Title> Element

The required metadata element <Title> identifies the mask by placing a label on the Mask Test panel as shown in the following figure. For example, the text "FC4250 PI Rev13" is shown in the picture. The string is automatically truncated to fit the available space on the panel.

Parent Elements

• <Mask>

Child Elements

None.

Attributes

None.

Example

• <Title>10Gb Ethernet</Title>
