1. Configuration

M9383B VXG-m, M9384B VXG, and M9484C VXG

Instrument Model Number

Displays the model number of the currently connected instrument.

Perform DC I/Q Calibration

Choice: On | Off

Default: On

Default: Off (M9381A)

Double-click or use the drop-down menu to enable or disable automatic DC I/Q calibration.

On − the signal generator automatically performs a DC I/Q calibration after downloading a waveform.

Off − the signal generator does not perform a DC I/Q calibration after downloading a waveform.

Baseband Channel Assignment

(M9383B/M9384B/M9484C only)

Choice: depends on the connected instrument

Default: 1

Sets the channel number for M9383B VXG-m, M9384B VXG, and M9484C VXG signal generators.
